Up to 0.05% Accuracy, Graphical Display, Data Logging Capability
Precision Digital Pressure Manometer is designed to measure and log pressure measurements. Ideal for laboratories and calibration facilities.
Features
-
Able to record up to 10,742 readings, which can be downloaded to a PC
-
Up to 0.05% accuracy for use in critical applications
-
Measure absolute, differential, or gage pressure
Product Applications
-
Calibration facilities
-
Laboratories
Specifications
-
Service: Air and compatible gases.
-
Wetted Materials: 18/8 stainless steel.
-
Accuracy: (Includes linearity, hysteresis, and repeatability): Depending on model. ±0.20% full-scale ±1 digit; ±0.10% full-scale ±1 digit; ±0.05% full-scale ±1 digit.
-
Temperature Limits: 32 to 122°F (0 to 50°C).
-
Storage Temperature: -4 to 140°F (-20 to 60°C).
-
Humidity: Maximum 95% RH non-condensing.
-
Display: Graphical back lit LCD. 128 x 64 points.
-
Power Requirements: (3) 1.5 V AA alkaline batteries, installed functional, user replaceable. Can operate on 6 to 9 VDC external power.
-
Current Consumption: 25 mA without back lit display, IR, or buzzer.
-
Memory: 10,742 readings. Recording intervals adjustable from 1 second to 24 hours or manual.
-
Case Protection: IP54 (NEMA 3).
-
Weight: 10.5 oz (300 g).
-
Process Connections: Hose 4/6 mm or 1/8" NPT.
-
Agency Approvals: CE.
