High Accuracy (0.2%, 0.1% or 0.05%), Differential, Gage or Absolute
Handheld Digital Manometer is designed to measure a wide range of pressures to a high accuracy.
Features
-
Measures differential, gage, or absolute pressure
-
Able to record up to 964 readings, which can be downloaded to a PC
-
Up to 0.05% accuracy
Product Applications
-
Calibration facilities
-
Laboratories
Specifications
-
Service: Air and compatible gases.
-
Accuracy: (Includes linearity, hysteresis, and repeatability): per order code. ±0.20% full scale ±1 digit. ±0.10% full scale ±1 digit. ±0.05% full scale ±1 digit.
-
Wetted Materials: 18/8 stainless steel.
-
Temperature Limits: 23 to 122°F (-5 to 50°C).
-
Storage Temperature: -4 to 140°F (-20 to 60°C).
-
Humidity: 30 to 95% rH, non-condensing.
-
Display: 2 line, 16 character, dot matrix LCD, with switchable display sizes.
-
Power Requirements: 9 V alkaline battery, installed functional, user replaceable. Can operate from external power supply of 7 to 14 VDC.
-
Current Consumption: <9 mA.
-
Memory: 964 measured values. Recording intervals adjustable from manual, 1, 5, 10, 20, 30 s, 1, 2, 3, 5, 10, 30, 60 m.
-
Case Protection: IP54 (NEMA 3).
-
Case Dimensions: 6" x 3.27" x 1.34" in (152 x 83 x 34 mm).
-
Weight: 9.5 oz (270 g).
-
Pressure Connection: Hose; 4/6 mm or 1/8" NPT.
-
Maximum Measurement Rates: Stand alone: 2-1/2 readings/sec (0.1% and 0.05% ratings), 5 readings/sec (0.2% rating). Output to RS-232: 20 measurements/sec (0.2% rating). 10 measurements/sec (0.1% and 0.05% ratings).
-
RS-232 Baud Rate: Adjustable, 1200, 2400, 4800, or 9600 baud.
-
Agency Approvals: CE.
