HART® Communication, Push Button Configuration, Rangeability (100:1)
Explosion-proof Differential Pressure Transmitter is a microprocessor which has a flexible pressure calibration, programmable with HART communication, and push button configuration.
Features
-
Configurable using zero/span buttons means no calibrator required reducing time to install and running
-
Range-ability and selectable engineering units, allows transmitter to fit many applications reducing the number of different transmitters to meet specifications
-
High accuracy (±0.075%) provides exceptional measurement for ensuring tight control and minimizing costly out of specification conditions
-
Automatic sensor temperature compensation improves performance of device for accurate measurement under different operating environments
-
Fail-mode process function stores configuration settings in the event of shutdown or power-loss provides for faster restart to getting application back on-line
-
A HART® Communication programmable device provides a reliable, long-term solution for plant operators who seek the benefits of intelligent devices with digital communication
Product Applications
Specifications
-
Service: Compatible gases, steam, liquids or vapors.
-
Wetted Materials: 316L SS, fluoroelastomer.
-
Accuracy: ±0.075% FS (@ 20°C).
-
Rangeability: 100:1 turn down.
-
Stability: ±0.125% FSO/yr.
-
Temperature Limits: Process: -40 to 248°F (-40 to 120°C); Ambient (without LCD): -40 to 185°F (-40 to 85°C); Ambient (with LCD): -22 to 176°F (-30 to 80°C).
-
Pressure Limits: Max. pressure: Range: -14.5 to 2000 psi; Burst pressure: 10000 psi.
-
Thermal Effect: ±0.125% span/32°C.
-
Power Requirements: 11.9 to 45 VDC.
-
Output Signal: 4 to 20 mA/HART® Communication.
-
Response Time: 0.12 seconds.
-
Damping Time: 0.25-60 seconds.
-
Loop Resistance: Operation: 0 to 1500 Ohm; HART® Communication: 250 to 500 Ohm.
-
Electrical Connection: Two 1/2" female NPT conduit, screw terminal.
-
Process Connection: 1/4" female NPT.
-
Display: Optional 5 digit LCD.
-
Enclosure Rating: NEMA 4X (IP66) and explosion-proof for Class I, Div I, Groups A, B, C and D.
-
Weight: 8.6 lb (3.9 kg).
-
Agency Approvals: CE, FM, ATEX option available (consult factory).
