Thông số kỹ thuật
- Service: Clean, compatible liquids.
- Wetted Materials: Brass and 316L SS.
- Range: See chart on catalog page.
- Display: 8-digit LED.
- Accuracy: BTU: EN1434/CJ128 Class 2; Flow: ±(2+(0.02 Qp / Q))%; Temperature: ±0.1°C.
- Power Requirements: 24 VDC/VAC (model dependent) or 3.6 V ER26500 lithium metal battery, user supplied and installed, battery acts as back-up if power is lost.
- Power Consumption: 1 W.
- Temperature Limits: Ambient: 41 to 131°F (5 to 55°C); Process: 36 to 203°F (2 to 95°C).
- Humidity Limit: <93%.
- Pressure Limits: 232 psi (16 bar) for DN15 to DN40; 362 psi (25 bar) for >DN50.
- Pressure Drop: <1.5 psi (10 kPa).
- Process Connection: See chart on catalog page.
- Serial Communications: Modbus® RTU or BACnet MSTP (selectable)**.
- Enclosure Rating: IP65.
- Enclosure Material: Plastic.
- Repeatability: Flowmeter: 1%.
- Electrical Connections: 3' (0.91 m) 4x0.2 mm2 cable with terminal block.
- Flow Direction: Unidirectional.
- Mounting Orientation: Horizontal or vertical.
- Weight: See chart on catalog page.
- Agency Approvals: CE.
**M-BUS available upon request.
