Thông số kỹ thuật
- Service: Non-corrosive gas.
- Wetted Materials: Brass with nickel plating.
- Housing Materials: Polycarbonate, polybutylene terephthalate.
- Accuracy: ±3% of full range.
- Pressure Limits: MDPC-1: 29 psi (200 kPa); MDPC-2: 217.6 psi (1500 kPa).
- Display: 2-line LCD display, 4 digits for measured value and 3.5 digits for setup display.
- Power Requirements: 12 to 24 VDC ±10% no isolations.
- Power Consumption: 40 mA max.; Current output type 60 mA max.
- Process Connections: 1/8" NPT, inner connection M5, for 1/8" PT contact factory.
- Weight: 1.3 oz (36.85 g).
- Agency Approvals: CE: MDPC-121, MDPC-122, UL.
SWITCH SPECIFICATIONS:
- Switch Type: NPN or PNP
- Electrical Rating: 100 mA @ 30 VDC.
- Response Time: Programmable to 2ms, 4ms, 10ms, 30ms, 50ms, 100ms, 250ms, 500ms, 1000ms or 5000ms.
- Display Cycle: Programmable to 100ms, 250ms, 500ms or 1000ms.
TRANSMITTER SPECIFICATIONS:
- Output Signal: 1 to 5 V: Minimum output load resistance 1000 Ω; 4 to 20 mA: Maximum output load resistance 400 Ω.
- Zero and Span Adjustments: Menu scalable within the range.
