Thông số kỹ thuật
- Service: Compatible gases and liquids.
- Wetted Materials: Type 316, 316L SS.
- Accuracy: 0.25% FS.
- Temperature Limit: 0 to 176°F (-18 to 80°C).
- Compensated Temperature Range: 0 to 176°F (-18 to 80°C).
- Thermal Effect: ±0.02% FS/°F (includes zero and span).
- Pressure Limits: See Catalog page.
- Power Requirements: 10 to 28 VDC.
- Output Signal: 4 to 20 mA.
- Response Time: 50 ms.
- Loop Resistance: 0 - 900 Ω maximum.
- Current Consumption: 38 mA (maximum).
- Electrical Connections: 3 ft. cable or 4-pin M-12 Connector.
- Process Connection: 1/4" male/female NPT and BSPT.
- Enclosure Rating: NEMA 4X (IP66).
- Mounting Orientation: Mount in any position.
- Weight: 8.9 oz (252 g).
- Agency Approvals: CE, cULus Intrinsically Safe to UL Standard 913.
- For use in Hazardous (Classified) Locations:
- * Class I Div. 1 Groups A,B,C,D; Class II Div. 1 Groups E,F,G; Class III Div. 1.
- * Temperature Code: T4 @ 80°C ambient.
- * Install in accordance with control drawing 01-700797-00.
WARNING: To prevent ignition of flammable or combustible atmospheres, disconnect power before servicing. Use with approved safety barriers using entity evaluation.
