3-1/2 Digits, Window Mount
LCD Digital Panel Meter accepts an input signal from a pressure, level, flow, or temperature transmitter. Applications include displaying process values from pressure, humidity, temperature, voltage, current, watt, or power factor transmitters.
Features
-
Window mounts
-
3-1/2 digit display with 0.45" (11 mm) segments
-
Colored segments available in black, red, amber, green, or blue
-
Jumper selectable engineering units and decimal point positions
Product Applications
-
Display process values from pressure, humidity, temperature, voltage, current, watt, or power factor transmitters
Specifications
-
Inputs: 4-20 mA DC.
-
Input Impedance: 300Ω nominal.
-
Accuracy: ±(0.1% FS + 2 count).
-
Power Supply: Powered by control loop.
-
Backlight Power Supply: 24 VDC @ 35 mA typical.
-
Span and Zero: Adjustable. (±1999).
-
Display: 3-1/2 digits, 7 segments, 0.45" (11.4 mm) H.
-
Decimal Points: 3-position, user selectable.
-
Engineering Units: DPMW-XXX: °F, °C, %, psi; DPMW-XXXP: V, A, KW, PF.
-
Polarity: Automatic, "-" displayed.
-
Operating Temperature: 32 to 122°F (0 to 50°C).
-
Storage Temperature: -4 to 158°F (-20 to 70°C).
-
Mounting: Window mount.
-
Connection: Screw terminals.
-
Conversion Rate: 3 per second.
-
Warm-Up: 10 minutes typical.
-
Weight: 2 oz (56.7 g).
-
Agency Approvals: RoHS.
