Set Points from 0.07" to 85" w.c. Repetitive Accuracy within 2%
Low Differential Pressure Switch for General Industrial Service which is ATEX approved and applies to mechanical equipment control and processes.
Features
-
Compact size and repeatability provide a high-value switch for many industrial applications
-
Designed for panel and wall mounting to easily meet mounting requirements in most industrial settings
-
Pressure ranges from 0.07 in w.c. to 85 in w.c. make this switch suitable for a wide range of applications
Product Applications
Specifications
-
Service: Air and non-combustible, compatible gases.
-
Wetted Materials: Consult Factory.
-
Temperature Limits: -30 to 180°F (-34 to 82.2°C). 1823-00, -20 to 180°F (-28.9 to 82.2°C).
-
Pressure Limits: 10 psig (68.95 kPa) continuous, 25 psig (172.4 kPa) surge.
-
Switch Type: Single-pole double-throw (SPDT).
-
Repeatability: ±2%.
-
Electrical Rating: 15 A @ 120-480 VAC, 60 Hz. Resistive 1/8 HP @ 125 VAC, 1/4 HP @ 250 VAC, 60 Hz. De-rate to 10 A for operation at high cycle rates.
-
Electrical Connections: 3 screw type, common, normally open and normally closed.
-
Process Connections: 1/8" female NPT.
-
Mounting Orientation: Diaphragm in vertical position. Consult factory for other position orientations.
-
Set Point Adjustment: Screw type inside mounting spud.
-
Weight: 1 lb, 5 oz (595 g).
-
Agency Approvals: CE, CSA, FM, UL. NOTE: Optional (-EXPL) Explosion-proof Enclosure does not possess any agency approvals.
